Product Overview
Features & Specifications: Popular stylish design Powerful 196cc 6.5HP OHV engine Electric start with pull start backup, can start without battery Fully automatic with reverse Torque converter CVT system, more low-end torque Canopy top Manual choke operating from dashboard LED headlight Horn All-wheel fenders Big tires: F /
Product Details & Specifications
| R | 16×6-8 / 16×7-8 Rack and pinion steering wheel Hydraulic disc brake Padding over roll cage Individual sporting seats Adjustable driver seat: pedal to seat back adjustable from 34” to 39” Easy assembly: put roll cages together, service battery, fill gas and go EPA certificated Engine type: 4-stroke, single cylinder, air cooled |
|---|---|
| Displacement: 200cc Max HP | 6.3hp/3600rpm Max torque: 9.6 lb ft/2500rpm Bore x stroke: 2.6 x 2.1 inches Max speed: 31mph Climbing ability: 12 degrees Ignition: C.D.I Starting system: Electric / Pull backup Battery: 12V 9Ah Carburetor brand: JF (RX) Engine oil: |
| SG15W-40 Clutch | Automatic CVT with reverse Driveline / Driving wheel: Chain / Dual wheel drive Suspension, F / |
| R | Double A-arm / Double Oil Damped Shock Brakes, F / |
| R | No / Hydraulic brake, Disc Tires, F / |
| R | 16×6-8 / 16×7-8 Fuel capacity: 1 gal Weight, G.W. / N.W.: 386 / 330 lbs Max load: 400 lbs Wheelbase: 48.4 inches OA L x W x |
| H | 67×43.3×51.2 inches Height to seat: 10.2 inches Min ground clearance: 2.8 inches Pedal to seat back distance: 34-39 inches |
